The basics post covered what each OSI layer does. This post covers how they interact in practice — the things that break in production and the tools to diagnose them.

Packet Captures with tcpdump
#

tcpdump lets you observe traffic at Layers 2–7 in real time. It’s the fastest way to confirm what’s actually happening on the wire.

Capture all traffic on an interface
#

sudo tcpdump -i eth0 -n

Filter by host and port
#

sudo tcpdump -i eth0 host 10.0.0.5 and port 443 -n

Capture to a file for Wireshark analysis
#

sudo tcpdump -i eth0 -w /tmp/capture.pcap -c 1000

Watch a TCP handshake
#

sudo tcpdump -i eth0 'tcp[tcpflags] & (tcp-syn) != 0' -n

Read specific fields
#

# Show packet sizes
sudo tcpdump -i eth0 -n -l | awk '{print $NF}'

# Show only RST packets (connection resets)
sudo tcpdump -i eth0 'tcp[tcpflags] & (tcp-rst) != 0' -n

What to look for:

Symptom	Likely Layer	Cause
SYN sent, no SYN-ACK	3/4	Firewall drop, host down, wrong route
SYN-ACK received, then RST	4/7	Port closed, application crashed
Retransmissions	3/4	Packet loss, congestion, MTU issues
Connection established, no data	7	Application-level bug, TLS failure

MTU and Fragmentation
#

MTU (Maximum Transmission Unit) is the largest packet size a link can carry. Standard Ethernet MTU is 1500 bytes.

Why MTU matters
#

When a packet exceeds the link’s MTU:

If the Don’t Fragment (DF) bit is set → packet is dropped, ICMP “fragmentation needed” is sent back
If DF is not set → packet is fragmented into smaller pieces

Detecting MTU issues
#

Path MTU discovery failures are a common cause of mysterious connectivity problems — connections establish (small packets) but hang when transferring data (large packets).

# Find the path MTU to a host
ping -c 4 -M do -s 1472 example.com
# If this fails, reduce size until it works
ping -c 4 -M do -s 1400 example.com

# Check interface MTU
ip link show eth0 | grep mtu

# Trace path MTU
tracepath example.com

Common MTU scenarios
#

Scenario	Effective MTU	Why
Standard Ethernet	1500	Default
VPN tunnel (WireGuard)	~1420	Tunnel headers consume space
PPPoE (some ISPs)	1492	PPPoE header is 8 bytes
Docker overlay network	~1450	VXLAN encapsulation overhead
Jumbo frames (datacenter)	9000	Must be configured end-to-end

Fixing MTU problems
#

# Set interface MTU
sudo ip link set eth0 mtu 1400

# Persistent (NetworkManager)
nmcli connection modify "Wired" 802-3-ethernet.mtu 1400

# Clamp TCP MSS in iptables (fixes MTU issues for TCP without changing MTU)
sudo iptables -t mangle -A FORWARD -p tcp --tcp-flags SYN,RST SYN -j TCPMSS --clamp-mss-to-pmtu

TCP Deep Dive
#

Connection states
#

A TCP connection transitions through states. Understanding these helps diagnose stuck connections:

LISTEN → SYN_RECEIVED → ESTABLISHED → FIN_WAIT_1 → FIN_WAIT_2 → TIME_WAIT → CLOSED
                                     → CLOSE_WAIT → LAST_ACK → CLOSED

# Count connections by state
ss -ant | awk '{print $1}' | sort | uniq -c | sort -rn

TIME_WAIT accumulation
#

After closing a connection, TCP enters TIME_WAIT for 2×MSL (usually 60 seconds). High-traffic servers can accumulate thousands:

# Count TIME_WAIT connections
ss -ant state time-wait | wc -l

# Check system limits
cat /proc/sys/net/ipv4/tcp_max_tw_buckets

If TIME_WAIT is exhausting ports:

# Enable socket reuse (safe for clients)
sudo sysctl -w net.ipv4.tcp_tw_reuse=1

# Make persistent
echo "net.ipv4.tcp_tw_reuse = 1" | sudo tee -a /etc/sysctl.d/99-tcp.conf

TCP window size and throughput
#

TCP window size limits how much data can be in-flight before an acknowledgment. On high-latency links, small windows throttle throughput:

# Check current TCP buffer sizes
sysctl net.ipv4.tcp_rmem
sysctl net.ipv4.tcp_wmem

# Increase for high-bandwidth links
sudo sysctl -w net.ipv4.tcp_rmem="4096 87380 16777216"
sudo sysctl -w net.ipv4.tcp_wmem="4096 65536 16777216"

Retransmissions
#

Retransmissions indicate packet loss. High retransmission rates degrade performance:

# Check retransmission stats
netstat -s | grep -i retrans

# Watch in real time
watch -n 1 'netstat -s | grep retrans'

# Per-connection retransmissions
ss -ti | grep -A1 retrans

NAT (Network Address Translation)
#

NAT rewrites packet headers at Layer 3, allowing multiple devices to share a single public IP.

Types of NAT
#

Type	Description	Use Case
SNAT	Rewrites source IP	Outbound traffic from private network
DNAT	Rewrites destination IP	Port forwarding, load balancing
Masquerade	SNAT with dynamic source IP	Home routers, VPNs

NAT with nftables
#

# Masquerade outbound traffic
sudo nft add table nat
sudo nft add chain nat postrouting { type nat hook postrouting priority 100 \; }
sudo nft add rule nat postrouting oifname "eth0" masquerade

# Port forward 8080 → internal server:80
sudo nft add chain nat prerouting { type nat hook prerouting priority -100 \; }
sudo nft add rule nat prerouting iifname "eth0" tcp dport 8080 dnat to 192.168.1.10:80

Diagnosing NAT issues
#

# View active NAT connections
sudo conntrack -L

# Count NAT table entries
sudo conntrack -C

# Check if NAT table is full
cat /proc/sys/net/netfilter/nf_conntrack_max
cat /proc/sys/net/netfilter/nf_conntrack_count

# Symptoms of NAT table exhaustion: new connections randomly fail
# Fix: increase the limit
sudo sysctl -w net.netfilter.nf_conntrack_max=262144

Firewalls Mapped to OSI Layers
#

Linux firewalls (iptables/nftables) operate across multiple layers:

Chain/Hook	OSI Layer	What it filters
Raw/prerouting	3	Before connection tracking
Mangle	3/4	Packet modification (TTL, TOS, MSS)
NAT	3/4	Address/port rewriting
Filter (input/forward/output)	3/4	Accept/drop decisions

nftables examples at different layers
#

# Layer 3: Block an IP
sudo nft add rule inet filter input ip saddr 10.0.0.50 drop

# Layer 4: Allow only specific ports
sudo nft add rule inet filter input tcp dport { 22, 80, 443 } accept
sudo nft add rule inet filter input drop

# Layer 4: Rate limit connections
sudo nft add rule inet filter input tcp dport 22 ct state new limit rate 3/minute accept

# Stateful filtering (Layer 4/5)
sudo nft add rule inet filter input ct state established,related accept
sudo nft add rule inet filter input ct state invalid drop

Diagnosing firewall drops
#

# Log dropped packets
sudo nft add rule inet filter input log prefix "DROPPED: " drop

# Watch the log
sudo journalctl -f | grep DROPPED

# Count drops per chain
sudo nft list ruleset | grep -c drop

VLAN Trunking (Layer 2/3 Boundary)
#

VLANs segment a physical network into logical broadcast domains at Layer 2.

Creating a VLAN interface
#

# Add VLAN 100 on eth0
sudo ip link add link eth0 name eth0.100 type vlan id 100
sudo ip addr add 10.100.0.1/24 dev eth0.100
sudo ip link set eth0.100 up

Inter-VLAN routing
#

Devices on different VLANs can’t communicate at Layer 2. They need a Layer 3 router:

# Enable IP forwarding (acts as router between VLANs)
sudo sysctl -w net.ipv4.ip_forward=1

# Device on VLAN 100 (10.100.0.0/24) can now reach VLAN 200 (10.200.0.0/24)
# if this host has interfaces on both VLANs

Diagnosing VLAN issues
#

# Verify VLAN is configured
cat /proc/net/vlan/config

# Check tagged traffic is arriving
sudo tcpdump -i eth0 -e vlan -n

# Common problem: switch port not set to trunk mode
# You'll see no traffic on the VLAN interface

L4 vs L7 Load Balancing
#

Load balancers operate at different OSI layers with different tradeoffs:

Layer 4 (Transport)
#

Routes based on IP and port. Doesn’t inspect content.

Client → [L4 LB] → Backend
         ↓
    Decision: IP hash, round-robin, least connections
    Sees: Source/dest IP, source/dest port
    Doesn't see: HTTP headers, URLs, cookies

Pros: Fast, low overhead, protocol-agnostic Cons: Can’t route based on content, no SSL termination

Example: Linux IPVS

# Install
sudo dnf install ipvsadm

# Add virtual service
sudo ipvsadm -A -t 10.0.0.1:80 -s rr

# Add backends
sudo ipvsadm -a -t 10.0.0.1:80 -r 10.0.0.10:80 -m
sudo ipvsadm -a -t 10.0.0.1:80 -r 10.0.0.11:80 -m

# Check status
sudo ipvsadm -L -n

Layer 7 (Application)
#

Inspects application content to make routing decisions.

Client → [L7 LB] → Backend
         ↓
    Decision: URL path, Host header, cookie, method
    Sees: Full HTTP request
    Can: Terminate TLS, rewrite headers, cache

Pros: Content-based routing, SSL termination, header manipulation Cons: Higher latency, more resource intensive, protocol-specific

Example: nginx as L7 load balancer

upstream api_servers {
    server 10.0.0.10:8080;
    server 10.0.0.11:8080;
}

upstream static_servers {
    server 10.0.0.20:80;
    server 10.0.0.21:80;
}

server {
    listen 443 ssl;

    location /api/ {
        proxy_pass http://api_servers;
    }

    location /static/ {
        proxy_pass http://static_servers;
    }
}

When to use which
#

Requirement	Use
Simple TCP/UDP distribution	L4
Route by URL or header	L7
Non-HTTP protocols (database, MQTT)	L4
SSL termination	L7
Maximum performance	L4
A/B testing, canary deploys	L7

Best Practices
#

Capture packets before guessing — tcpdump eliminates speculation
Test MTU end-to-end when setting up VPNs or overlay networks
Monitor TIME_WAIT and conntrack table size on high-traffic systems
Log firewall drops — silent drops are the hardest to troubleshoot
Choose load balancer layer based on whether you need content awareness
When debugging, correlate layers — a Layer 7 timeout might be caused by Layer 3 packet loss
